Multi Bag Filter

These multi bag filter offer a wide range of flow capacities and contaminant-holding capabilities. They contain from 2 to 18 support-baskets.The standard pressure rating for all models is 150 psi. All multi bag filter housings can be supplied with an ASME code stamp, if required.

Price：￥0.00

■Multiple housing styles available (standard, quick access, low profile, hinged)

■Permanently piped housings are opened without tools and without disturbing the piping

■Machined cover gasket groove provides positive O-ring sealing

■Large-area, 30 inch deep, heavy-duty, 9/64 inch perforated baskets

■Easy to clean

■Low pressure drop

■Four cover seal materials: Buna N, Ethylene Propylene, Viton®, and Teflon®

■Pressure rating 150 psi

■Flanged connections for 2 through 12 inch pipe

■Vent, drain and gage connections

■Carbon steel, 304 or 316L stainless steel construction housings

■automotive coatings

■copper foil

■food and beverage

■pulp and paper

■paints,inks,resins and coatings

■electronics

■slilicon industry

■water treatment
